Honey processing machine adopt an electric heating or steam heating structure, automatic temperature control, and vacuum feed, the device not only can concentrate but can sterilization, this equipment adopts 304 stainless steel, easy to operate, reliable operation, highly efficient, vacuum suction honey, can achieve higher vacuum degree and low concentrated temperature, is the ideal of honey processing equipment. Equipment includes a preheating tank, filters, concentrator, condenser, and vacuum pump.
- Function: Removing honey moisture and filtering
- Model: FM-600 FM-400
- Material: All stainless steel 304
- Vacuum degree: -0.092 Mpa
- Feature: Double Tanks
- Power: 16kw
- Capacity: 0.5-1.5t per 8h
Price: $2900-3290 /Set
honey processing line
Structural drawing
Working Principle
Taking advantage of the property that the boiling point of honey decreases at low temperatures, the excess water in the honey is evaporated at a relatively low temperature under vacuum; at the same time, the auxiliary equipment provided is used to complete the treatment processes of honey removal, sterilization and crystal nucleation.
Features
This equipment uses a gentle water bath heating method, crystal nucleation technology, and a rising film decompression evaporation process to ensure that the quality of honey is not damaged during the processing process.
It has the advantages of a beautiful appearance, easy installation, convenient operation, safety and reliability, cleaner water extraction, and higher honey purity. It is made of 304 stainless steel and meets the national QS food hygiene standards. It is an excellent equipment to improve efficiency, shorten time, reduce costs, and improve labor.
Technical parameters
| Model | FM600 | FM400 |
|---|---|---|
| Production capacity | 1.2-1.5 t/8h | 0.5 t/8h |
| Machine diameter | 1750*600*1660 mm | 1600*500*1555 mm |
| Tank diameter | 600 mm | 400 mm |
| Thank height | 600 mm | 600 mm |
| The overall volume | 140 L | 70 L |
| Effective volume | 120 L | 60 L |
| Preheat tank power | 6 KW | 6 KW |
| Volume concentration tank power | 9 KW | 6 KW |
| Vacuum pump power | 1.5 KW | 1.5 KW |
